Replaceable Parts 135
Table 5-12. A4A2/A4A4 Right Tunnel Board Parts List for 500 Watt 655xA & 665xA Models (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
R309 0757-0280 Resistor 1K 1% .125W
R310 65/6651A, 65/6652A, 0698-3454 Resistor 215K 1%
65/6653A
65/6654A, 65/6655A 0757-0470 Resistor 162K 1%
R311 65/6651A, 65/6652A 0811-3849 Resistor 0.25 5% 3W
6653 0811-3848 Resistor 0.39 5% 3W
6654 0811-3847 Resistor 0.66 1% 3W
6655 0811-1220 Resistor 1.5 5% 3W
R312 65/6651A-65/6654A 0698-3430 Resistor 21.5 1%
65/6655A 8159-0005 Resistor 0 Ohms
R313 65/6651A-65/6654A 0698-3441 Resistor 215 1% .125W
6655 Not used
R314 0757-0280 Resistor 1K 1% .125W
R315 65/6651A, 65/6652A, 0757-0465
65/6654A, 65/6655A
6653 0757-0470 Resistor 162K 1%
R316 65/6651A, 65/6652A 0811-3849 Resistor 0.25 5% 3W
6653 0811-3848 Resistor 0.39 5% 3W
6654 0811-3847 Resistor 0.66 1% 3W
6655 0811-1220 Resistor 1.5 5% 3W
R317 65/6651A-65/6654A 0698-3430 Resistor 21.5 1%
65/6655A 8159-0005 Resistor 0 Ohms
R318 65/6651A-65/6654A 0698-3441 Resistor 215 1% .125W
6655 Not used
R319 0757-0280 Resistor 1K 1% .125W
R320 65/6651A, 65/6652A, 0757-0463 Resistor 82.5K 1%
65/6654A, 65/6655A
6653 0757-0465 Resistor 100K
R323 0683-0475 Resistor 4.7 5% .25W
R325-328 65/6651A 0811-3849 Resistor 0.25 5% 3W
6652-55
R329-332 65/6651A-65/6654A Not used
65/6655A 0698-3430 Resistor 21.5 1%
U301,302 1826-0962 IC 412
1200-1158 Transistor socket (ref Q301, 303, 305,307)
0515-0064 Screw-mach M3 x .5 16mm lg pan
head (ref Q301,303, 305, 307)
2190-0584 Washer-lk (ref Q301, 303, 305, 307)
