Maintaining the Instrument
Checking carousel adjustment
102
Figure 25. Misaligned carousel
If the elevator rod and bushing do not line up exactly under the hole in the
carousel cylinder, call Agilent service.
Hole in cylinder
Elevator rod
Rod bushing
