Getting Started

Programming

Example

# Reset the instrument to start from a defined, default status.

*RST

# Switch off the automatic display update to increase programming

# speed

:DISPlay OFF

# Set the output function of output 1 to pulse.

:FUNCtion1 PULSe

# Set the period to 500 ns, the pulse width to 100 ns

# Settings are programmed for output 1.

:PULSe:PERiod1 500NS

:PULSE:WIDTh1 100NS

# enable burst mode and set the burst length to 4

:TRIGger1:COUNt 4

# Enable the output 1 and the complement output 1.

:OUTput1 ON

:OUTput1:COMPlement ON
