Agilent Technologies 8163B Programming Guide

Measurement Operations & Settings Signal Conditioning
154 Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Fifth Edition
command:
:OUTPutn[:CHANnel[m]]:POWer:OFFSet
syntax: :OUTPutn[:CHANnel[m]]:POWer:OFFSet<wsp><value>[DB] | MIN | MAX | DEF
description: Sets a power offset (P
offset
). This factor is used to offset the power value. It does not affect
the filter, nor does it change the power output at the attenuator module.
P
set(new)
(dBm) = P
att
(dBm) - P
offset(new)
(dB)
If the wavelength offset table is enabled, the corresponding λ offset is added to this offset.
parameters: <value>
MIN | MAX | DEF
The power offset required, in dB
Queries the module limits, or the default.
response: none
example: OUTP1:POW:OFFS 2
affects: Attenuator modules with power control.
command:
:OUTPutn[:CHANnel[m]]:POWer:OFFSet?
syntax: :OUTPutn[:CHANnel[m]]:POWer:OFFSet? <wsp>MIN | MAX| DEF
description: Without the optional parameter, queries the power offset value.
parameters: MIN | MAX | REF Queries the power offset limits, or the module default.
response: 4 byte Intel floating point; power offset in current power units.
example: OUTP1:POW:OFFS? → 2<END>
affects: Attenuator modules with power control.
command:
:OUTPutn[:CHANnel[m]]:POWer:OFFSet:POWermeter
syntax: :OUTPutn[:CHANnel[m]]:POWer:OFFSet:POWermeter<wsp><slot>,<channel>
description: Calculates the power offset by subtracting the power value measured by another powerme-
ter (hosted by the same mainframe) from the power value measured by the attenuator’s inte-
grated powermeter, and stores it as P
offset
.
P
offset(new)
(dBm) = P
att
(dBm) - P
ext
(dBm) + P
offset ( λ )
(dB)
parameters: <slot>
<channel>
Slot number of the external powermeter.
Channel number of the external powermeter.
response: none
example: OUTP1:POW:OFFS:POW 4,4
affects: Attenuator modules with power control.
