Instrument Setup and Status Status Reporting – The STATus Subsystem
64 Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Fifth Edition
Status Reporting – The STATus
Subsystem
The Status subsystem allows you to return and set details from the Status
Model. For more details, see “The Status Model” on page 33.
command:
:STATus:OPERation[:EVENt][:LEVel0]?
syntax: :STATus:OPERation[:EVENt][:LEVel0]?
description: Returns the Operational Status Event Summary Register (OSESR).
parameters: none
response: The sum of the results for the slots (a 16-bit signed integer value, where 0 ≤ value ≤ 32767):
Bits Mnemonics Decimal Value
Agilent 8163A/B Agilent 8164A/B Agilent 8166A/B
15 Not used Not used Not used 0
14 Not used Not used Slot 14 Summary 16384
13 Not used Not used Slot 13 Summary 8192
12 Not used Not used Slot 12 Summary 4096
11 Not used Not used Slot 11 Summary 2048
10 Not used Not used Slot 10 Summary 1024
9 Not used Not used Slot 9 Summary 512
8 Not used Not used Slot 8 Summary 256
7 Not used Not used Slot 7 Summary 128
6 Not used Not used Slot 6 Summary 64
5 Not used Not used Slot 5 Summary 32
4 Not used Slot 4 Summary Slot 4 Summary 16
3 Not used Slot 3 Summary Slot 3 Summary 8
2 Slot 2 Summary Slot 2 Summary Slot 2 Summary 4
1 Slot 1 Summary Slot 1 Summary Slot 1 Summary 2
0 Not used Slot 0 Summary Level 1 Summary 1
example: stat:oper? → +0<END>
