Agilent Technologies 8163B Programming Guide

The Agilent 816x VXIplug&play Instrument Driver Using Visual Programming Environments
222 Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Fifth Edition
7
Click on the Next > button.
8 The Identify Found Instruments… window appears, click on the Next >
button.
9 The Update VXI Plug and Play Drivers window appears, select HP816X,
and click on the Convert button.
10 The Manage Instrument Drivers window appears, click on the Finish
button.
11 The first window appears again, click on the New VI button.
12 Select File and then select Convert CVI FP file.
13 The Select a CVI Function Panel file window appears, locate the
hp816x.fp file, which is normally installed into the path
<drive>:VXIPNP\winXX\hp816x, where XX stands for NT, or 95.
14 Press Open.
15 The CVI Function Panel Converter window appears.
16 Click on Browse… and browse to the following Destination Directory:
\LabView\instr.lib\hp816x\hp816x.llb
17 Press Save.
18 Press Options…, the FP Conversion Options window appears. Check
that the options are the same as displayed in the figure below:.
Figure 16 FP Conversion Options Box
