Chapter 2 77
Adjustment/Diagnostic Software
10. DC Log Adjustment
1. Connect the 3335A to the INPUT 50Ω of the spectrum analyzer
being adjusted.
2. Carefully follow the instructions issued by the software program.
See Figure 2-8, “DC Log Adjustment Locations,” for adjustment
locations.
Figure 2-8 DC Log Adjustment Locations
