124 Chapter2
Making Adjustments
17. Time and Date
17. Time and Date
This adjustment applies to:
All 8590 E-Series and L-Series spectrum analyzers
8591C cable TV analyzers
8594Q QAM analyzers
The time and date are displayed in the top left corner of the display
when the timedate mode is activated. The time and date are changed
using the front-panel keys.
Procedure
1. To turn the time and date ON or OFF, press the following analyzer
keys.
CONFIG
TIMEDATE
TIMEDATE ON OFF (ON) or (OFF) as desired
The time and date will be displayed in the top-left corner with ON
underlined.
2. The time and date may be displayed as month, day, and year (MDY)
or as day, month, and year (DMY). To change the display, press the
following analyzer keys.
CONFIG
TIMEDATE
DATEMODE MDY DMY (MDY) or (DMY) as desired
3. To change the date, press the following analyzer keys.
CONFIG
TIMEDATE
SET DATE
The active function block of the analyzer will display YYMMDD (year,
month, and day). Use the data keys on the analyzer to enter the
correct date as YYMMDD. Terminate the entry with one of the
ENTER
data keys.
