358 Chapter9
Assembly Descriptions and Block Diagrams
Assembly Descriptions and Block Diagrams
Assembly Descriptions and Block Diagrams
Component-level information for the 8590 E-Series and L-Series
spectrum analyzers, 8591C cable TV analyzers, and 8594Q QAM
analyzers is provided in the 8590 Series Analyzers Component-Level
Repair Service Guide. Refer to Chapter 12 for a list of available
component-level service information.
The 8590 E-Series and L-Series spectrum analyzers, 8591C cable TV
analyzers, and 8594Q QAM analyzers are microprocessor-controlled
swept receivers covering the following frequency ranges. The overall
description briefly describes each of the major analyzer assemblies.
Table 9-1 8590 E-Series and L-Series Spectrum Analyzer, 8591C Cable TV
Analyzer, and 8594Q QAM Analyzer Frequency Ranges
Analyzer Model Frequency Range
8590L 9 kHz to 1.8 GHz
8591C 1 MHz to 1.8 GHz
8591E 9 kHz to 1.8 GHz
8592L 9 kHz to 22.0 GHz
8592L (Option 026) 9 kHz to 26.5 GHz
8592L (Option 027) 9 kHz to 26.5 GHz
8593E 9 kHz to 22.0 GHz
8593E (Option 026) 9 kHz to 26.5 GHz
8593E (Option 027) 9 kHz to 26.5 GHz
8594E 9 kHz to 2.9 GHz
8594L 9 kHz to 2.9 GHz
8594Q 9 kHz to 2.9 GHz
8595E 9 kHz to 6.5 GHz
8596E 9 kHz to 12.8 GHz
