254 Chapter5
Troubleshooting the IF Section
Before You Start
Before You Start
There are four things you should do before starting to troubleshoot an
analyzer failure.
• Check that you are familiar with the safety symbols marked on the
analyzer, and read the general safety instructions and the symbol
definitions given in the front of this guide.
• The analyzer contains static sensitive components. Read the section
entitled “Protection from Electrostatic Discharge” in.
• Become familiar with the organization of the troubleshooting
information in this service guide.
• Read the rest of this section.
WARNING The analyzer contains potentially hazardous voltages. Refer to
the safety symbols on the analyzer and the general safety
considerations in the front of this guide before operating the
unit with the cover removed. Failure to heed the safety
precautions can result in severe or fatal injury.
Service Equipment You Will Need
Refer to the table entitled, “Recommended Test Equipment,” in
Chapter 1 of the 8590 Series Analyzers Calibration Guide for a list of
the recommended test equipment needed to troubleshoot and repair the
analyzer. Although Agilent Technologies equipment is recommended,
any equipment that meets the critical specifications given in the table
can be substituted for the recommended model.
Refer to Chapter 15, “Service Equipment and Tools” of this guide for a
list of recommended service tools and required hand tools needed to
troubleshoot and repair the analyzer.
