3-49
Function Reference
Next Pit Up ↑
Next Pit Up ↑
Places the active marker on the next lowest pit from the current marker
amplitude. This pit must meet the pit excursion and threshold criteria. If the
specified marker is off, it will be turned on and placed at the center wave-
length. The search for the next minimum will reference that point.
Key Path Markers > More Marker Functions > Marker Search Menu > Next Pit
↑
Remote
Commands
CALCulate[1|2|3|4|5|6]:MARKer[1|2|3|4]:MINimum:NEXT
Noise Marker
Measures the spectral power density at the position of the active marker. The
measurement is referenced to 0.1 nm or 1.0 nm reference bandwidth. The ref-
erence bandwidth used to normalize the noise is selected on the marker setup
panel.
Note For Agilent 86144B/86146B only, if filter mode is enabled, the noise marker,
delta marker, and OSNR marker are disabled.
Key Path Markers > More Marker Functions > Noise Marker
Related Functions Active Marker
Remote
Commands
CALCulate:MARKer:FUNCtion:NOISe:STATe OFF|ON|0|1
