6-4
Maintenance
Printer Head Cleaning Procedure
Printer Head Cleaning Procedure
Lint from normal use of the printer may eventually collect on the printer head
and degrade print quality. Use the procedure provided in this section to clean
the printer head. Also refer to “Changing the Printer Paper” on page 6-2.
WARNING This servicing procedure is for use by qualified personnel only. To
avoid electrical shock, do not perform this procedure unless you are
qualified to do so.
CAUTION Electrostatic discharge (ESD) can damage or destroy the printer. Therefore,
this procedure must always be performed at a static-safe work station.
Static-safe Work
Station
Figure 6-1 on page 6-5 shows an example of a static-safe work station using
conductive table and floor mats and wrist and heel straps. To ensure user
safety, the static-safe accessories must provide at least 1 M
Ω of isolation from
ground. Refer to Table 6-1 for information on ordering static-safe accessories.
Table 6-1. Static-Safe Accessories
Agilent Part
Number
Description
9300-0797
3M static control mat 0.6 m
× 1.2 m (2 ft× 4 ft) and 4.6 cm (15 ft) ground
wire. (The wrist-strap and wrist-strap cord are not included. They must be
ordered separately.)
9300-0980 Wrist-strap cord 1.5 m (5 ft).
