Agilent 86144B/86146B Additional Specifications
WARNING The light emitted from the MONOCHROMATOR INPUT connector is filtered
and slightly attenuated light input to the front-panel MONOCHROMATOR
INPUT connector. Light can radiate from the front panel in the following
instrument modes: filter mode, external path, and stimulus response.
NOTE The following 86144B and 86146B specifications are for the 9 µm filter mode only.
Table 7-10. Additional Specifications–Agilent 86144B/86146B
Table 7-11. Additional Specifications–Agilent 86144B/86146B
Insertion Loss Stability
a
1550 nm
15 minutes
a. Immediately following enhanced single point auto align, at constant temperature.
0.5 dB
Insertion Loss
b
1550 nm
b. For room temperature only.
10 dB max
Agilent 86146B Agilent 86144B
Filter Bandwidth
a
,
b
a. From 1530-1610 nm
b. Characteristic
0.5 dB 1.0 dB 3.0 dB 0.5 dB 1.0 dB 3.0 dB
RBW Nominal
Setting
Actual Bandwidth
0.04 nm
0.016 0.023 0.039 0.016 0.023 0.039
0.05 nm 0.019 0.026 0.045 0.019 0.026 0.045
0.07 nm
0.033 0.044 0.063 0.033 0.044 0.063
0.1 nm
0.076 0.089 0.115 0.076 0.089 0.115
0.2 nm
0.134 0.147 0.173 0.134 0.147 0.173
0.3 nm
0.257 0.270 0.297 0.257 0.270 0.297
0.5 nm 0.421 0.434 0.460 0.421 0.434 0.460
±20% ±30%
