7-13
Specifications and Regulatory Information
Specifications
Characteristic Monochromator Loss
a. Second order is selected when the stop wavelength is at or below 900 nm and resolution is <10 nm
b. With applied input fiber that is standard single mode at wavelength of interest.
c. At room temperature.
d. Characteristic
e. With applied input fiber 9/125
µm.
f. Temperature range 20
°C to 30°C
g. To within 20 dB of the sensitivity noise limit.
h. Sensitivity applied within 1 minute of last zeroing
Monochromator Loss
0
–3
–6
–9
–12
–15
–18
–21
–24
–27
1st Order
2nd Order
700 800 900 1000 1100 1200 1300 1400 1500 1600
nm
1550850
