Agilent Technologies 86140B Series

7-15
Specifications and Regulatory Information
Specifications
Table 7-12. Filter Bandwidth
Adjacent Channel
Rejection (at 1550nm)
a
a. Characteristic
Agilent 86146B Agilent 86144B
12.5 GHz 25 GHz 50 GHz 100 GHz 50 GHz 100 GHz
±0.1 nm ±0.2 nm ±0.4 nm ±0.8 nm ±0.4 nm ±0.8 nm
0.04 nm 40 dB 50 dB 55 dB 55 dB 50 dB 50 dB
0.05 nm 40 dB
50 dB 55 dB 55 dB 50 dB 50 dB
0.07 nm ---- 50 dB 55 dB 55 dB 50 dB 50 dB
0.1 nm ---- 40 dB 50 dB 55 dB 45 dB 50 dB
0.2 nm ----
40 dB 45 dB 55 dB 40 dB 50 dB
0.3 nm ---- ---- 45 dB 55 dB 40 dB 50 dB
0.5 nm ---- ---- 45 dB 50 dB 40 dB 45 dB
