Agilent Technologies 86140B Series User Manual

7-16
Specifications and Regulatory Information
Specifications
Table 7-13. Option 001 Current Source
Current Output
Agilent 86140B, 86141B, 86142B, 86146B Only
Range
0 to
±200 mA (source or sink)
Resolution
a
a. Characteristic
50 µA steps
Accuracy
2% ±50 µA
Clamp Voltage
b
b. Nominal
±2.7V
Noise Density at 1 kHz
a
<4 nA/
Stability Within 30 Minutes
a
<100 ppm ±500 nA
Temperature Drift
a
<(100 ppm ±500 nA)/°C
Pulse Mode
Pulse Range
Pulse Resolution
Duty Cycle Range
10
µs to 6.5 ms
100 ns
Pulse width/1 s to 100%
Hz
