Agilent Technologies 8719ES Service Guide

2-44 Service Guide
System Verification and Performance Tests 8719ET/20ET/22ET
Performance Tests 8719ES/20ES/22ES
RF Network Analyzers
Calibration
6. Connect a thru (RF cable) between PORT 1 and PORT 2 on ES models (REFLECTION
and TRANSMISSION on ET models).
7. To start the measurement calibration, press the following:
8. Remove the thru and connect 50
Ω terminations to PORT 1 and PORT 2 on ES models
(REFLECTION port and TRANSMISSION port on ET models).
9. To continue the measurement calibration, press the following:
NOTE This measurement takes several minutes
10.When the analyzer beeps or the message, PRESS ‘DONE’ IF FINISHED WITH STD(s),
appears on the display, press the following:
Measurement and Data Collection
11.Press .
12.When the single sweep has been taken, press the following:
13.Read the mean value and standard deviation from the analyzer display. Calculate the
dynamic range, using the following equation.
20 × log [(3 × Standard Deviation) + Mean Value]
Record the calculated value in the “S21 / Transmission” column of the “Dynamic Range”
performance test record for your analyzer.
14.Repeat steps 12 and 13 (beginning with ), placing marker 1 and
marker 2 at the start and stop of the remaining frequency ranges that are listed in
Table 2-13.
Cal
CALIBRATE MENU
RESPONSE &ISOL’N
RESPONSE
THRU
Avg
AVERAGING FACTOR
8
x1
AVERAGING ON
Cal
RESUME CAL SEQUENCE
ISOL’N STD
DONE:RESP ISOL’N CAL
Sweep Setup
TRIGGER MENU
SINGLE
Scale Ref
AUTOSCALE
Marker Fctn
MARKER MODE MENU
MARKERS: DISCRETE
Marker
MARKER 1
50 M/µ
MARKER 2
50.000101 M/µ
Marker Fctn
MARKER MODE MENU
MKR STATS ON
Marker
∆ MODE MENU
∆ REF=1
Marker
MARKER 1
