5-22
Supplement for the Reference Guide (Firmware Revision 7.68)
Error Messages
ECal: REFLECTION STATE
Information
Message
This message is displayed when the ECal module is set to the reflection state.
ECal: SELECTING BEST REFECTION REFLECTION STATE
Information
Message
The network analyzer is in the process of selecting the most accurate reflection
response.
ECal: SELECT OTHER MODULE
Error Number
221
This error occurs when two ECal modules are connected. The selected ECal
module may not be able to measure the selected frequency range. Check the
frequency range of the other module and connect in the RF path.
ECal: THRU STATE
Information
Message
This message is displayed when the ECal module is set to the thru state.
ISOL AVERAGES < SWP AVERAGES
Error Number
223
The isolation averages are less than the instrument sweep averages. Increase
the isolation averages to be equal to or greater than instrument sweep averages.
This error can only occur when instrument averaging is turned on.
NO MODULE DATA FOR THIS PARAMETER
Information
Message
This message is displayed in Ecal service when there is no parameter data in
the ECal module.
NO MODULE DATA FOR ISOLATION STD
Information
Message
This message is displayed in ECal service when there is no isolation data in the
ECal module.
OK TO ALTER CORRECTION CONSTANTS?
Error Number
186
This message is displayed as a prompt during operations when the correction
constants will be changed. Correction constants may be change in the
adjustment tests in the service menu.
SELECTED MODULE OUTSIDE START-STOP FREQ RANGE
Error Number
220
The start and stop frequency range is outside the limits of the ECal module.
Manually set the frequency limits to within the module range.
