5-23
Supplement for the Reference Guide (Firmware Revision 7.68)
Error Messages
VALID ONLY FOR BILATERAL DEVICES
Information
Message
This message is displayed when an enhanced reflection calibration is initiated.
If the device tested is not a bilateral device, the enhanced reflection calibration
will cause errors in the measurement results.
A bilateral device has similar forward and reverse transmission characteristics.
Examples of bilateral devices are passive devices (filters, attenuators, and
switches). Most active devices (amplifiers) and some passive devices (isolators
and circulators) are not bilateral.
WAIT: ECal MODULE BEING READ
Information
Message
The data from ECal is being read by the network analyzer.
