Unpacking and Installation
Agilent Cary 600 Series FTIR Spectrometers and Microscopes User’s Guide 31
Microscope
Power to the instrument and purge line (if used) is connected at the
rear of the instrument:
To connect the power and purge lines to the microscope:
1 Make sure the power switch on the rear of the microscope is in
the off (0) position.
Figure 8. Power switch and socket on the rear of the microscope. USB to PC
cable also shown.
2 Connect the power cord to the rear of the microscope.
3 Connect the other end of the power cable to the electrical power
outlet.
4 For purging of the microscope, connect the gas purge line to the
fitting on the rear of the microscope upper cover.
CAUTION
Use only dry air or dry nitrogen to purge the spectrometer and/or microscope.
