Automatic Measurement Controls
Automatic Measurement Procedure
2-58
Automatic Measurement Procedure
1 Select either CH1 or CH2 according to the waveform you want to measure.
2 To see all time and voltage measurement values, set the
Display All menu
to
ON.
3 Select the
Voltage or Time menu button to display the list of
measurements.
4 Select the desired measurement menu button. The measurement result
is displayed at the bottom of the screen. If the measurement result is
displayed as "*****", then the measurement cannot be performed with
the current oscilloscope settings.
5 Press the
Clear menu button to remove the individual automatic
measurements from the screen.
