2-43
Display Controls
Figure 2-26 shows location of the Display button in the Waveform area of the
front panel.
Figure 2-26
Display Menu
Pressing the Display button produces the Display menu as follows:
Table 2-14
Display Menu 1
When the display Type is set to Vectors, the oscilloscope connects the sample
points by using digital interpolation. Digital interpolation maintains linearity by
using a sin(x)/x digital filter. The digital interpolation is suitable for real time
sampling and is most effective at 20 ns or faster horizontal scale settings.
Menu Setting Comments
Type Vectors
Dots
Display waveforms as vectors
Display waveforms as dots
Grid Display grids and axes on the screen
Turn off the grids
Turn off the grids and axes
Persist Infinite
OFF
The sample points remain displayed until persistence is set to "OFF" or
Clear is pressed
Turn off the persistence function
Clear Clears waveforms from the display
To Next Page
