Chapter 6 Replaceable Parts
E3631-60005 Front Frame Assembly
116
E3631-60005 Front Frame Assembly
E3631-60005 Power SupplyAssembly
Reference
Designator
Agilent Part
Number
Qty Description Mfr
Code
Mfr Part Number
C32(Bottom) 0180-2980 1 CAP-FXD 1000uF +-20% AL-ELCTLT 55680
SME50VB102M16X25LL
C42-C43(Top) 0180-4355 2 CAP-FXD 470uF +-20% AL-ELCTLT S4217 UPF1H471MRH
E3631-80007 1 FRONT LABEL 28480 E3631-80001
E3631-40016 1 KEYPAD 28480 E3631-40005
E3631-20011 3 BINDING POST RED 28480 1510-0135
E3631-20013 1 BINDING POST GREEN 28480 E3631-20008
E3631-20012 2 BINDING POST BLACK 28480 1510-0136
E3631-40015 1 FRONT FRAME 28480 E3631-40001
E3631-40012 1 WINDOW PLATE FOR FRONT 28480 E3631-20004
E3631-40017 1 KNOB 28480 E3631-40006
E3631-60003 1 VFD BOARD ASSEMBLY 28480 E3631-60003
E3631-60009 1 CHASSIS GROUND ASSEMBLY2 28480 E3631-60009
E3631-60011 1 +6V OUTPUT & SENSING WIRE ASSEMBLY 28480 E3611-60011
E3631-60016 1 25V OUTPUT & SENSING WIRE ASSEMBLY 28480 E3631-60016
Reference
Designator
Agilent Part
Number
Qty Description Mfr
Code
Mfr Part Number
E3631-60017 1 DC FAN HARNESS ASSY 28480 E3631-60017
E3631-60020 1 TRANSFORMER BRACKET ASSEMBLY 28480 E3631-60020
9100-5385 1 MAIN TRANSFORMER 28480 9100-5585
E3631-00007 1 COVER 28480 E3631-00004
E3631-40010 1 BUMPER-FRONT 28480 E3631-40003
E3631-40011 1 BUMPER-REAR 28480 E3631-40004
E3631-40007 1 PUSH ROD 28480 E3631-40007
E3631-40013 1 STRAP HANDLE 28480 E3631-40008
5041-9607 2 REAR CAP 28480 5041-8834
E3631-40014 1 REAR BEZEL 28480 E3631-40002
E3631-60018 1 FLAT WIRE 28480 E3631-60018
E3631-60013 1 CONTROL & BIAS HARNESS 28480 E3631-60013
E3631-60006 1 AC INLET ASSEMBLY 28480 E3631-60006
E3631-60005 1 FRONT FRAME ASSEMBLY 28480 E3631-60005
