Agilent Technologies E3631A Service Manual

Chapter 2
Quick Start
To rack mount the power supply
36
To rack mount the power supply
The power supply can be mounted in a standard 19-inch rack cabinet using one
of three optional kits available. A rack-mounting kit for a single instrument is
available as Option 1CM (P/N 5062-3957). Installation instructions and
hardware are included with each rack-mounting kit. Any Agilent Technologies
System II instrument of the same size can be rack-mounted beside the Agilent
E3631A power supply. To rack mount the power supply, follow these
procedures.
Remove the front and rear bumpers before rack-mounting the power supply.
To remove the rubber bumper, stretch a corner and then slide it off.
To rack mount a single instrument, order adapter kit 5063-9243.
Front
Rear (bottom view)
