Chapter 2 Quick Start
To check the rated voltages of the power supply
26
5 Check the voltage function for the +25V supply.
Select the meter and adjust selection key for the +25V supply. The CV
annunciator is still lit and the +25V annunciator will turn on. Repeat steps (3)
and (4) to check the voltage function for the +25V supply.
6 Check the voltage function for the -25V supply.
Select the meter and adjust selection key for the -25V supply. The CV
annunciator is still lit and the -25V annunciator will turn on. Repeat steps (3)
and (4) to check the voltage function for the -25V supply.
+25V
-25V
