Agilent Technologies E3634A Service Guide

Chapter 3 Calibration Procedures
Performance Test Record for Agilent E3633A and E3634A
60
Performance Test Record for Agilent E3633A and E3634A
CV Performance Test Record
CC Performance Test Record
Test Description Models Actual Result
Specifications
Upper Limit Lower Limit
CV Programming Accuracy @ 0
volts (DVM reading)
both +0.0100 V -0.0100 V
CV Readback Accuracy @ 0 volts both DVM + 0.0050 V DVM - 0.0050 V
CV Programming Accuracy
@ Full Scale (DVM reading)
(E3633A) +20.0200 V 19.9800 V
(E3634A) +50.0350 V 49.9650 V
CV Readback Accuracy @ Full Scale (E3633A) DVM + 0.0150 V DVM - 0.0150 V
(E3634A) DVM + 0.0300 V DVM - 0.0300 V
CV Load Effect (Load Regulation) Maximum change: < (4 mV)* or (7 mV)**
CV Source Effect (Line Regulation) Maximum change: < (4 mV)* or (7 mV)**
CV PARD (Normal mode) < 3 mV p-p, (350 mV)* or (500 mV)** rms
Load Transient Response Time both < 50 msec
Test Description Models Actual Result
Specifications
Upper Limit Lower Limit
CC Programming Accuracy
@ 0 amps (I
O
)
both +0.0100 A -0.0100 A
CC Readback Accuracy @ 0 amps both I
O
+ 0.0050 A I
O
- 0.0050 A
CC Programming Accuracy
@ Full Scale (I
O
)
(E3633A) 20.0500 A 19.9500 A
(E3634A) 7.0230 A 6.9770 A
CC Readback Accuracy @ Full Scale (E3633A) I
O
+ 0.0350 A I
O
- 0.0350 A
(E3634A) I
O
+ 0.0155 A I
O
- 0.0155 A
CC Load Effect (Load Regulation) Maximum change: < (2.25 mA)* or (0.95 mA)**
CC Source Effect (Line Regulation) Maximum change: < (2.25 mA)* or (0.95 mA)**
CC PARD (Normal mode) both < 2 mA rms
CC PARD (Common mode) both < 1.5 mA rms
*For Agilent E3633A Model **For Agilent E3634A Model
