Appendix Service Information
Recommended Test Equipment
179
Service
Information
Recommended Test Equipment
The test equipment recommended for the performance verification and adjustment
procedures is listed below. If the exact instrument is not available, use the accuracy
requirements shown to select substitute calibration standards. If you use equipment
other than that recommended in Table A-2, you must recalculate the measurement
uncertainties for the actual equipment used.
Table A-2 Recommended Test Equipment
*
To find the accurate resistance, it is recommended to use a current monitoring resistor after calibration.
1
E3646A model,
2
E3647A model,
3
E3648A model,
4
E3649A model.
Instrument Requirements Recommended Model Use
GPIB controller Full GPIB or RS-232
capabilities
Agilent 82341C interface
card or equivalent
Programming and readback
accuracy
Oscilloscope 100 MHz with 20 MHz
bandwidth
Agilent 54602B Display transient response and
ripple & noise waveform
RMS Voltmeter 20 Hz to 20 MHz Measure rms ripple & noise
Cable (BNC to BNC) 50 ohm, 9 inch (23 Cm) Agilent 10502A or 10503A if
the 10502A is not available.
Measure rms ripple & noise
(CV PARD, CC PARD)
BNC (Female)
Bulkhead Receptacle
Isolated Ground.
Nominal impedance: 50 Ohm
Pomona Model 5148 Measure rms ripple & noise
(CV PARD, CC PARD)
Split Ferrites For use with round cable Steward Co. 28A2029-0A0 Noise coupling reduction
Digital Voltmeter Resolution: 0.1 mV
Accuracy: 0.01%
Agilent 34401A Measure dc voltages
Electronic Load Voltage Range: 240 Vdc
Current Range: 10 Adc
Open and Short Switches
Transient On/Off
Agilent 60503B Measure load and line
regulations and transient
response time.
Resistive Loads (R
L
) (2.7 Ω, 150 W/13.5 Ω, 150 W)
1
(43.8 Ω, 300 W/120 Ω, 300 W)
2
(1.6 Ω, 300 W/8.0 Ω, 300 W)
3
(25 Ω, 300 W/75 Ω, 300 W)
4
Measure ripple and noise
Current monitoring
Resistor (Shunt) - R
M1
(0.01 Ω, 0.1%)
*
ISOTEK Co. Model: A-H or
equivalent
Constant current test setup
Current monitoring
Resistor (Shunt) - R
M2
(0.1 Ω/ 5 W, 1%)
*
Vishay Co. Model: LVR-5-
43 or equivalent
Measure current rms ripple &
noise
To Next Page
