Agilent Technologies E3648A User Manual

Chapter 4 Remote Interface Reference
Simplified Programming Overview
83
4
Power Supply Programming Ranges
The SOURce subsystem requires parameters for programming values. The available
programming value for a parameter varies according to the desired output range of
the power supply. The following table lists the programming values available and
MINimum, MAXimum, DEFault and reset values of your power supply.
Refer to this table to identify programming values when programming the power
supply.
T
able 4-1. Agilent E3646A/47A/48A/49A Programming Ranges
E3646A E3647A E3648A E3649A
0 - 8V/
3A
Range
0 - 20V/
1.5A
Range
0 - 35V/
0.8A
Range
0 - 60V/
0.5A
Range
0 - 8V/
5A
Range
0 - 20V/
2.5A
Range
0 - 35V/
1.4A
Range
0 - 60V/
0.8A
Range
Voltage Programming
Range
0 V to
8.24 V
0 V to
20.60 V
0 V to
36.05 V
0 V to
61.8 V
0 V to
8.24 V
0 V to
20.60 V
0 V to
36.05 V
0 V to
61.8 V
MAX Value 8.24 V 20.60 V 36.05 V 61.8 V 8.24 V 20.60 V 36.05 V 61.8 V
MIN Value 0 V 0 V 0 V 0 V
DEFault Value 0 V 0 V 0 V 0 V
*RST Value 0 V 0 V 0 V 0 V
Current Programming
Range
0 A to
3.09 A
0 A to
1.545 A
0 A to
0.824 A
0 A to
0.515 A
0 A to
5.15 A
0 A to
2.575 A
0 A to
1.442 A
0 A to
0.824 A
MAX Value 3.09 A 1.545 A 0.824 A 0.515 A 5.15 A 2.575 A 1.442 A 0.824 A
MIN Value 0 A 0 A 0 A 0 A
DEFault Value 3 A 1.5 A 0.8 A 0.5 A 5 A 2.5 A 1.4 A 0.8 A
*RST Value 3.00 A 0.8 A 5.00 A 1.4 A
