Agilent Technologies E4404B Getting Started Guide

78 Chapter 5
Options and Accessories
Options
225 Distance to Fault
Measurement Personality
Performs a Fast Fourier Transform to calculate the distance to a
cable fault. This option must be ordered with tracking generator
(Option 1DN). This measurement includes on-screen
instructional dialog to guide set up and calibration. Velocity
factor and cable loss can be user-defined or selected from several
different pre-defined cable types.
106
Bluetooth
 FM
Demodulation
Option 106 is required to perform FM demodulation on signals
measured with the Bluetooth
 Measurement Personality (Option
228).
Option 106 allows you to demodulate, display and measure
deviation of Bluetooth
 FM modulated signals. You can listen to
audio signals on a built-in speaker or with an earphone.
Option 106 provides the following additional port:
EXT VIDEO OUT - provides a detected video output
(before the analog-to-digital conversion) proportional to the
vertical deflection of the trace (75 ).
228
Bluetooth
 Measurement
Personality
Provides transmitter and receiver measurements required to test
Bluetooth
 devices. The set of Bluetooth measurements
includes:
• Modulation Overview
• Output Power
• Carrier Frequency Drift
• Monitor Band/Channel
• Initial Carrier Frequency Tolerance
• Modulation Characteristics
Option 228 includes: Bluetooth
 user’s guide, Bluetooth
quick reference card, Bluetooth
 measurement guide, and
Bluetooth
 programming commands manual.
Bluetooth
 FM Demodulation (Option 106) is required for full
functionality of this personality.
304
Bluetooth
 Premium
Bundle
Provides the following:
• Bluetooth
 FM demodulator (Option 106)
• Bluetooth
 measurement personality (Option 228)
• high stability frequency reference (Option 1D5)
• digital signal processing and fast ADC (Option B7D)
• RF communications hardware (Option B7E)
• enhanced memory upgrade (Option B72)
• RF preamplifier (Option 1DS)
227 Cable TV Measurement
Personality
Provides measurement capabilities necessary for installation and
service of cable TV systems.
Option
Number
Name Description
