Chapter 5 79
Options and Accessories
Options
BAC cdmaOne Measurement
Personality
Provides transmitter and receiver measurements that comply with
various international digital communications standards. The
measurements include:
• channel power
• receiver channel power
• modulation accuracy (RHO)
• code domain power
• receiver spurious
• out-of-band spurious
• harmonics
• occupied bandwidth
• monitor channel/band
• close-in spur
For optimum performance of this personality, Option COM with
RF Preamplifier (Option 1DS) is recommended.
BAH GSM Measurement
Personality
Provides transmitter and receiver measurements that comply with
various international digital communications standards. The
measurements include:
• Transmit power
• Power steps
• Power versus time
• Spurious emissions suite
• Intermodulation attenuation suite
• Phase and frequency error
• Cable fault location suite
• Slow frequency hopping cycle verification
• Monitor suite
• Output RF spectrum suite
For optimum performance of this personality, Option COM with
Time-Gated Spectrum Analysis (Option 1D6) and RF
Preamplifier (Option 1DS) are recommended.
252 EDGE Measurement
Personality
This option works with the GSM personality, Option BAH. It
provides additional transmitter and receiver measurements that
comply with the digital communications standards. The
measurements include:
• EDGE power versus time
• EDGE EVM (error vector magnitude)
• EDGE output RF spectrum suite
Option
Number
Name Description
