Chapter 4
Front-Panel Key and SCPI Command Reference
Measure
163
Front-Panel Key and SCPI Command
Reference
4.3.8 Modulation Rate
Allows the user to switch to the Modulation Rate measurement.
4.3.8.1 SCPI Remote Commands
:CONFigure:MODRate
:INITiate:MODRate
:FETCh:MODRate[n]?
:MEASure:MODRate[n]?
:READ:MODRate[n]?
Mode: MRECEIVE
Key Path:
Measure, More
Remote Command: :CONFigure:MODRate
Notes: This key invokes Modulation Rate Measurement.
Example: :CONF:MODR
Index: n
<Mnemonic>
Results Returned
0 Returns unprocessed I/Q trace data, as a series of comma-separated trace points, in volts. The I
values are listed first in each pair, using the 0 through even-indexed values. The Q values are the
odd-indexed values.
not specified or
n = 1
Returns comma-separated scalar results, in the following order:
Return the measured modulation rate (Hz).
Modulation Rate Ratio (–999 in Normal mode, Ratio: dB or % depending on Ratio Mode setting)
Ratio Reference Frequency (Hz)
Return demodulated result(% for AM, Hz for FM, and rad for PM)
Return modulation distortion(%)
Return modulation sinad(dB)
To Next Page
