28 Chapter 2
Front and Rear Panel Features
Front Panel Overview
25
Average
a
Trace/Avg, Average: The number
shown indicates current average
number.
VAvg: voltage average
LgAv: log power average
PAvg power average
26 Display line annotation
Display, Display Line
27 Amplitude offset Amplitude, Ref Lvl Offst
28 Amplitude scale Amplitude, Scale Type or Amplitude, Scale/Div
29
Phase noise optimization
a
Auto Couple, PhNoise Opt
Phase noise can be optimized for:
f<50k: frequencies less than 50 kHz from carrier.
f>50k: frequencies greater than 50 kHz from carrier.
FTun: LO for fast tuning.
30
Sweep type
a
Sweep, Sweep Type
31 Signal track
Could also be CP (Continuous Peak)
Frequency, Signal Track
Peak Search
, Continuous Pk
a. This function can be auto-coupled. A pound (#) symbol in front of this annotation indicates an
uncoupled function.
Ite
m
Description Associated Function Keys
To Next Page
