Chapter 1 9
Installation and Setup
Initial Inspection
Initial Inspection
Inspect the shipping container and the cushioning material for signs of stress.
Retain the shipping materials for future use, as you may wish to ship the analyzer
to another location or to Agilent Technologies for service. Verify that the contents
of the shipping container are complete. The following table lists the items shipped
with the analyzer.
Item Description
Accessories
IntuiLink Toolbar software, CD-ROM Provides a set of connectivity tools that enable you to easily move data
from your analyzer to your PC.
Power Cable Connection for power source.
USB Cable (Option 111 only) Connects PSA USB to USB on a PC, part number 8121-1074.
Adapter (E4446A, E4447A, and E4448A only) 2.4 mm(f) to K(f) front panel connector adapter, part number
1250-2187.
Adapter (E4446A, E4447A, and E4448A only) 2.4 mm(f) to 2.4 mm(f) front panel connector adapter, part number
1250-2188.
Agilent Automation-Ready CD Assists in quickly and properly connecting instruments to your PC,
part number E2094-60003. Includes: Agilent IO Libraries Suite,
Agilent VEE Pro, T&M Tool Kit, and Agilent IO Hardware
information.
Standard Documentation Set
Getting Started Guide Covers unpacking and setting up the analyzer, analyzer features, and
how to make a basic measurement. Includes information on options
and accessories, and what to do if you have a problem.
User’s and Programmer’s Reference Describes analyzer features in detail, including front-panel key
descriptions, basic spectrum analyzer programming information, and
SCPI command descriptions.
Measurement Guide Provides details on how to measure various signals, and how to use
catalogs and files.
Specifications Guide Documents specifications, safety, and regulatory information.
Instrument Messages and Functional Tests Includes instrument messages (and suggestions for troubleshooting
them), and manual functional tests.
Programming Conversion Guide Describes SCPI programming command compatibility for 8590, 8560,
8566, 8568, ESA/PSA series analyzers.
Documentation CD-ROM Includes the documents in the standard set (listed above). You can
view and print the information as needed. See the CD-ROM jacket for
installation information.
