106 Chapter 2
Front-Panel Key Reference
File
Key Access: File, Rename
Name
Accesses the Alpha Editor and allows you to enter a
filename. The external keyboard can also be used to
enter a filename while the alpha editor is accessed.
Complete your entry by pressing
Return or Enter.
NOTE Only capital letters (A-Z) and digits (0-9) may appear in file names
(8 characters, maximum). Additionally, file names include a 3 character
extension which is automatically set by the instrument.
Key Access:
File, Rename
Dir Up
Allows you to move up one directory level. If at the top
level,
Dir Up moves to the drive level, displaying the
available disk drives.
Key Access:
File, Rename
Dir Select
Accesses the highlighted directory on your display.
Key Access:
File, Rename
Create Dir
Allows you to create subdirectories.
Key Access:
File, More
Create Dir
Now
Executes the create directory function. When the
directory has been created, the message Directory
XXXXXX created (where XXXXXX is the directory
name) will appear in the status line on your display.
Key Access:
File, More, Create Dir
Name
Accesses the Alpha Editor and allows you to enter a
filename. The external keyboard can also be used to
enter a filename while the alpha editor is accessed.
Complete your entry by pressing
Return or Enter.
Key Access:
File, More, Create Dir
NOTE Only capital letters (A-Z) and digits (0-9) may appear in file names
(8 characters, maximum). Additionally, file names include a 3 digit
extension which is automatically set by the instrument.
Dir Up Allows you to move up one directory level. If at the top
level, Dir Up moves to the drive level, displaying the
available disk drives.
Key Access:
File, More, Create Dir
Dir Select
Accesses the highlighted directory on your display.
Key Access:
File, More, Create Dir
