4-46 Service Guide E8364-90026
Troubleshooting PNA Series Microwave Network Analyzers
Measurement System Troubleshooting E8362B, E8363B, E8364B
Table 4-8 LO Path Frequencies
Model Band
Network Analyzer
Frequency Band
of Problem (GHz)
Network Analyzer
Source Frequency
Setting (GHz)
Expected A17
Output
Frequency
(GHz)
Expected A18
Output
Frequency
(GHz)
E8362B, E8363B, E8364B
0 0.010 to 0.045 0.025 0.026 0.026
1 0.045 to 0.748 0.500 0.508 0.508
2 0.748 to 1.500 1.000 1.008 1.008
3 1.50 to 3.00 2.200 2.208 2.208
4 3.00 to 3.80 3.400 3.408 3.408
5 3.80 to 4.50 4.200 4.208 4.208
6 4.50 to 4.80 4.600 4.608 4.608
7 4.80 to 6.00 5.400 5.408 5.408
8 6.00 to 6.40 6.200 6.208 6.208
9 6.40 to 7.60 7.000 7.008 7.008
10 7.60 to 10.00 8.800 8.808 8.808
11 10.00 to 12.00 11.000 5.504 11.008
12 12.00 to 12.80 12.400 6.204 12.408
13 12.80 to 15.20 14.000 7.004 14.008
14 15.20 to 16.00 15.600 7.804 15.608
15 16.00 to 20.00 18.000 9.004 18.008
E8363B, E8364B
16 20.00 to 22.80 21.400 7.136 7.136
17 22.80 to 25.60 24.200 8.069 8.069
18 25.60 to 30.00 27.800 9.269 9.269
19 30.00 to 32.00 31.000 5.168 10.336
20 32.00 to 36.00 34.000 5.668 11.336
21 36.00 to 38.40 37.200 6.201 12.403
22 38.40 to 40.00 39.200 6.535 13.069
E8364B
23 40.00 to 45.60 42.800 7.135 14.269
24 45.60 to 48.00 46.800 7.801 15.602
25 48.00 to 50.00 49.000 8.168 16.336
