6-78 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
Hard Disk Drive Assembly
Reference
Designator
Part Number Qty Description
N8980A
a
Kit (for 500 MHz CPU board)
-or-
N8981A
a
Kit (for 1.1 GHz CPU board)
a. Assembly includes A41 HDD and all hardware listed in this table.
Hard disk drive assembly kit with
programmed hard disk drive (HDD)
(Includes A41 and items
➀
through
➆
, pre-assembled.)
A41
E8801-60063 (for 500 MHz CPU board)
-or-
E8364-60190 (for 1.1 GHz CPU board)
1 Programmed hard disk drive (HDD)
➀
E8364-20118 1 Hard disk drive bracket
➁
0515-0664 4 Machine screw, M3.0 x 12, pan head
➂
0515-0372 2 Machine screw, M3.0 x 8, pan head
➃
0340-1525 8 Bushing
➄
E8364-60094 1 Hard disk drive board
➅
1440-0421 1 U-handle, finger grip
➆
0515-1227 2
Machine screw, M3.0 x 6, flat head
(for U-handle,
➅
)
To Next Page
