6-72 Service Guide E8364-90026
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362B, E8363B, E8364B
Internal Hardware and Parts, All Options
Ref. Desig. Models Part Number Qty Description
A40 All
0950-2782 1 Floppy disk drive
8121-0120 1 Cable
E4406-60014 1 Floppy disk drive board
E4406-40006 1 Floppy disk drive mount
E8356-00007 1 Floppy disk drive enclosure
B1 All 3160-1085 3 Fan
➀
All E8356-00027 1 Chassis assembly
➁
All E8364-00013 1 Test set deck
➂
E8362B E8362-00003
1 Test set deck front panel
E8363B, E8364B E8364-00014
➃
All
These feed-through connectors, including the nuts and washers, are part of the
individual cables. Refer to the appropriate bottom semi-rigid cables illustration in
this chapter to determine the part number of the cable assembly.
➄
All E8356-40004 1 Line switch button
➅
All 1460-2632 1 Line switch spring
➆
All E4406-60109 1 Midweb assembly (includes three fans)
➇
All 0515-1227 8 Machine screw, M3 x 6, flathead
To Next Page
