Service Guide E8364-90026 3-5
PNA Series Microwave Network Analyzers Tests and Adjustments
E8362B, E8363B, E8364B Before You Begin
Review the Principles of Connector Care
Proper connector care and connection techniques are critical for accurate and repeatable
measurements. Refer to Table 3-1 for tips on connector care.
Prior to making connections to your analyzer, carefully review the information about
inspecting, cleaning, and gaging connectors. Refer to the calibration kit documentation for
detailed connector care information.
For course numbers about additional connector care instruction, contact Agilent
Technologies. Refer to “Contacting Agilent” on page 2-13.
Table 3-1 Connector Care Quick Reference Guide
Handling and Storage
Do • Keep connectors clean Do Not • Touch mating-plane surfaces
• Extend sleeve or connector nut • Set connectors contact-end down
• Use plastic end-caps during storage • Store connectors or adapters loose
Visual Inspection
Do • Inspect all connectors carefully Do Not • Use a damaged connector - ever
• Look for metal particles, scratches,
and dents
Connector Cleaning
Do • Try compressed air first Do Not • Use any abrasives
• Use isopropyl alcohol
a
a. Cleaning connectors with alcohol shall only be done with the instrument’s power cord
removed, and in a well-ventilated area. Allow all residual alcohol moisture to evaporate,
and the fumes to dissipate prior to energizing the instrument.
• Get liquid into plastic support
beads
• Clean connector threads
Gaging Connectors
Do • Clean and zero the gage before use Do Not • Use an out-of-specification
connector
• Use the correct gage type
• Use correct end of calibration block
• Gage all connectors before first use
Making Connections
Do • Align connectors carefully Do Not • Apply bending force to connection
• Make preliminary connection contact
lightly
• Over tighten preliminary
connection
• Turn only the connector nut • Twist or screw any connection
• Use a torque wrench for final
connection
• Tighten past torque wrench
“break” point
