Service Guide E8364-90026 7-5
PNA Series Microwave Network Analyzers Repair and Replacement Procedures
E8362B, E8363B, E8364B Removal and Replacement Procedures
A22 Switch splitter Page 7-42
A23 Detector (E8363B and E8364B only)
Page 7-46
A24 Detector (E8363B and E8364B only)
A25 Test port 1 coupler
Page 7-48
A26 Test port 2 coupler
A27 Channel A first converter (mixer)
Page 7-50
A28 Channel R1 first converter (mixer)
A29 Channel R2 first converter (mixer)
A30 Channel B first converter (mixer)
A31 Channel A receiver module
Page 7-52
A32 Channel R1 receiver module
A33 Channel R2 receiver module
A34 Channel B receiver module
A35 Receiver motherboard Page 7-54
A36 Port 1 60-dB source step attenuator (Option UNL)
Page 7-56
A37
Port 2 60-dB source step attenuator (Option UNL)
A38 Port 1 bias tee (Option UNL)
Page 7-58
A39 Port 2 bias tee (Option UNL)
A40 Floppy disk drive Page 7-60
A41
Hard disk drive
Page 7-62
A43 Channel A 35-dB receiver step attenuator (Option 016)
Page 7-68
A44 Channel B 35-dB receiver step attenuator (Option 016)
A45 Channel R1 reference channel transfer switch (Option 081)
Page 7-70
A46
Channel R1 reference channel transfer switch (Option 081)
A47 RF path coupler (Option H11)
Page 7-72
A48 LO path coupler (Option H11)
A49 IF multiplexer board (part of A31, A32, A33, A34 procedure) Page 7-52
Table 7-1 List of Procedures
