Index
Service Guide E8364-90026 Index-11
N
N2721A software
tests, 3-31
network analyzer, See analyzer
noise floor, test , 3-35
noise, trace noise test , 3-33
Non-ANSI/NCSL Z540-1-1994
verification, 3-10
nut
test port coupler
illustrated
, 6-69, 6-71
part number, 6-68, 6-70
O
OCXO (oven-controlled crystal
oscillator)
frequency adjustment, 3-41
theory of operation
, 5-9
offset receiver
troubleshooting, 4-57
operating environment
specifications, 3-4
verification
, 3-4
operating system
recovery, 8-20
operation
bias tees, 5-18
configurable test set, Option 014
,
5-18
CPU board
, 5-32
data acquisition
, 5-32
detectors, 5-17
digital control
, 5-29
digital processor
, 5-29
display assembly, 5-31
first converters
, 5-21
fixed attenuators
, 5-17
floppy disk drive
, 5-33
fractional-N synthesizer
, 5-8
fractional-N synthesizer board
,
5-24
frequency offset group
, 5-24
frequency offset receiver
, 5-24
frequency reference board
, 5-9
front panel
, 5-31
front panel interface board
, 5-31
hard disk drive
, 5-33
IF access group
, 5-26
IF multiplexer board
, 5-21, 5-26
keypad assembly
, 5-31
LO path coupler
, 5-26
LODA
, 5-9
LOMA 10, 5-9
MA 20
, 5-9
main RAM
, 5-32
phase lock board, 5-10
power supply
, 5-34
processing subgroup
, 5-32
receiver group
, 5-21
receiver mixers, 5-21
receiver modules
, 5-21
receiver motherboard
, 5-23
reference transfer switches, 5-24
RF path coupler
, 5-26
signal separation group
, 5-16
SOMA 50, 5-11
source
, 5-6
source assembly
, 5-10
source group, band modes, 5-6
SPAM board–analog
, 5-23
SPAM board–digital
, 5-32
splitter assembly
, 5-9
step attenuators
receiver
, 5-18
source, 5-18
switch splitter (A22)
, 5-16
system motherboard
, 5-31
test port couplers, 5-17
test set motherboard
, 5-12
USB hub
, 5-33
operator’s check , 3-11
accessories used in, 3-11
dialog box
, 3-12
failure of
, 3-12
performing, 3-11
Port 1
, 3-11
Port 2
, 3-11
option
data
recovering
, 8-17
repairing
, 8-17
enable utility
accessing
, 8-15
dialog box
, 8-15
enabling and removing
, 8-16
entitlement certificate
, 8-15
hardware
, 8-16
service and support
, 2-12
software
, 8-16
Option 010, time domain , 2-3
Option 014, configurable test set ,
2-3
block diagram, 5-19
normal configuration
, 5-19
operation
, 5-18
Option 016
receiver attenuators, 5-18
Option 016, receiver attenuators ,
2-4
Option 040, extended frequency to
40 GHz , 2-4
Option 050, extended frequency to
50 GHz , 2-4
Option 067, extended frequency to
67 GHz , 2-4
Option 080, frequency offset mode ,
2-4
Option 081, transfer switch , 2-5
Option 099, firmware upgrade , 2-5
Option 1CM, rack mount without
handles , 2-6
Option 1CP, rack mount with
handles , 2-6
Option 897
built-in tests for commercial
calibration
, 2-5
Option 898
built-in tests for standard
compliant calibration
, 2-5
Option H08, pulse measurement
capability
, 2-6
Option H11
IF access
operation, 5-26
Option H11, IF access , 2-6
operation verification, 3-30
Option R-50C-001, calibration
certificate and data , 2-12
Option R-50C-002, standards
compliant calibration , 2-12
Option UNL, 60-dB source step
attenuators , 5-18
Option UNL, replaceable parts
illustrated, 6-25, 6-27
part numbers, 6-24, 6-26
Option UNL, source attenuator ,
2-6
Option UNL/014
replaceable parts
illustrated
, 6-33, 6-35
part numbers, 6-32
Option UNL/014/016
replaceable parts
illustrated
, 6-43
part numbers
, 6-40
Option UNL/014/016/080/081
replaceable parts
illustrated
, 6-57, 6-59, 6-61,
6-63
part numbers
, 6-56, 6-60
Option UNL/014/080/081
replaceable parts
illustrated
, 6-49, 6-51, 6-53,
6-55
part numbers
, 6-48, 6-52
Option UNL/016
replaceable parts
illustrated
, 6-37, 6-39
part numbers
, 6-36, 6-38
options
analyzer, 2-3
ordering information
calibration options, 2-12
options and upgrades
, 2-3, 2-7
replaceable parts, 6-3
