6-4 Service Guide E8364-90038
Replaceable Parts PNA Series Microwave Network Analyzers
Assembly Replacement Sequence E8362C, E8363C, E8364C
Assembly Replacement Sequence
The following steps show the sequence that you should follow to replace an assembly in the network
analyzer.
Step 1. Identify the faulty group. Begin with Chapter 4, “Troubleshooting.” Follow up with the appropriate
troubleshooting chapter that identifies the faulty assembly.
Step 2. Order a replacement assembly. Refer to this chapter.
Step 3. Replace the faulty assembly and determine what adjustments are necessary. Refer to Chapter 7,
“Repair and Replacement Procedures.”
Step 4. Perform the necessary adjustments. Refer to Chapter 3, “Tests and Adjustments.”
Step 5. Perform the necessary performance tests. Refer to Chapter 3, “Tests and Adjustments.”
