6-74 Service Guide E8364-90038
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362C, E8363C, E8364C
Internal Hardware and Parts, All Options
Ref. Desig. Models Part Number Qty Description
B1 All 3160-1085 3 Fan
➀
All E8356-00027 1 Chassis assembly
➁
All E8364-00013 1 Test set deck
➂
E8362C E8362-00003
1 Test set deck front panel
E8363C, E8364C E8364-00014
➃
All
These feed-through connectors, including the nuts and washers, are part of the
individual cables. Refer to the appropriate bottom semi-rigid cables illustration in
this chapter to determine the part number of the cable assembly.
➄
All E8356-40004 1 Line switch button
➅
All 1460-2632 1 Line switch spring
➆
All E4406-60109 1 Midweb assembly (includes three fans)
➇
All 0515-1227 8 Machine screw, M3 x 6, flathead
➈
All
E4406-60109 1 Midweb assembly (includes three fans, B1)
➉
All
E8364-00021 1 Clamp, ribbon cable
All
0515-0374 1
Machine screw M3.0 x 10, pan head (for cable clamp,
item
➉
)
