7-74 Service Guide E8364-90038
Repair and Replacement Procedures PNA Series Microwave Network Analyzers
Removing and Replacing the A47 and A48 Couplers (Option H11) E8362C, E8363C, E8364C
Removing and Replacing the A47 and A48 Couplers (Option H11)
Tools Required
T-10 TORX driver (set to 9 in-lb)
T-20 TORX driver (set to 21 in-lb)
5/16-inch open-end torque wrench (set to 10 in-lb)
ESD grounding wrist strap
Removal Procedure
Refer to Figure 7-33 for this procedure.
1. Disconnect the power cord.
2. Remove the outer cover. Refer to “Removing the Covers” on page 7-6. Position the analyzer bottom side
up and raise the receiver deck as shown. Refer to “Raising the Receiver Deck” on page 7-8 if necessary.
3. Locate the coupler to be removed; the A47 RF path coupler or the A48 LO path coupler. The A47 RF path
coupler is secured to the analyzer side frame (test set deck) and the A48 LO path coupler is secured to a
bracket which also holds the A19 splitter.
4. To remove the A47 RF path coupler:
a. With a 5/16-inch wrench, disconnect the three semirigid cables from the coupler.
CAUTION Be careful not to damage the center pins of the semirigid cables. Some flexing of the cables
is necessary for removal. Do not over-bend them.
b. With a T-10 TORX driver, remove the mounting screws holding the coupler.
5. To remove the A48 LO path coupler:
a. With a 5/16-inch wrench, disconnect the three semirigid cables from the coupler and the three
semirigid cables from the A19 splitter.
b. With a T-10 TORX driver, remove the mounting screws from the bracket that holds the A48 LO path
coupler and the A19 splitter.
6. Remove the bracket, with the A48 LO path coupler attached, from the analyzer. Observe the
CAUTION
above.
7. Remove the A48 LO path coupler from the bracket by removing the attachment screws.
Replacement Procedure
1. Reverse the order of the removal procedure using the existing cables and hardware.
2. Perform the post-repair adjustments, verifications, and performance tests that pertain to this removal
procedure. Refer to Table 7-2 on page 7-82.
