6-48 Service Guide E8364-90038
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8362C, E8363C, E8364C
Bottom Semi-Rigid Cables, Options 014/080/081
Ref. Desig. Models Part Number Qty Description
W1
E8362C E8362-20002
1
A12 source 20 to A22 switch splitter
E8363C, E8364C E8364-20036 A12 source 20 to A21 SOMA 50
W2 E8363C, E8364C E8364-20034 1 A21 SOMA 50 to A22 switch splitter
W3
E8362C E8362-20003
1
A22 switch splitter to channel R1 30-dB attenuator
E8363C, E8364C E8364-20144 A22 switch splitter to A23 detector
W4
E8362C E8362-20004
1
A22 switch splitter to channel R2 30-dB attenuator
E8363C, E8364C E8364-20024 A22 switch splitter to A24 detector
W11 All E8364-20171 1 A20 LODA to A27 channel A mixer
W12 All E8364-20172 1 A20 LODA to A28 channel R1 mixer
W13 All E8364-20173 1 A20 LODA to A29 channel R2 mixer
W14 All E8364-20146 1 A20 LODA to W40 (to A30 channel B mixer)
W15 All E8364-20041 1 A19 splitter to A20 LODA
W16 All E8364-20042 1 A19 splitter to A20 LODA
W17 All E8364-20029 1 A18 MA 20 to A19 splitter
W18 All E8364-20145 1 A17 LOMA 10 to A18 MA 20
W19-W20 All
Refer to “Top Cables–All, All Options Except 080” on page 6-16
.
W40 All E8364-20032 1 W14 (from A20 LODA) to A30 channel B mixer
W60
E8362C 08720-20098
6Front-panel jumper
E8363C, E8364C E8364-20059
W61
E8362C E8362-20016
1 A22 switch splitter to port 1 SOURCE OUT
E8363C, E8364C E8364-20081
W62
E8362C E8362-20017
1 A22 switch splitter to port 2 SOURCE OUT
E8363C, E8364C E8364-20082
W63
E8362C E8362-20018
1 Port 1 CPLR THRU to A25 test port 1 coupler
E8363C, E8364C E8364-20073
W64
E8362C E8362-20019
1 Port 2 CPLR THRU to A26 test port 2 coupler
E8363C, E8364C E8364-20074
W65
E8362C E8362-20007
1
Channel R1 attenuator to channel R1 SOURCE OUT
E8363C, E8364C E8364-20047 A23 detector to channel R1 SOURCE OUT
W66
E8362C E8362-20053
1
Channel R2 attenuator to channel R2 SOURCE OUT
E8363C, E8364C E8364-20048 A24 detector to channel R2 SOURCE OUT
W67
E8362C E8362-20020
1 A25 test port 1 coupler to Port 1 CPLR ARM
E8363C, E8364C E8364-20043
W68
E8362C E8362-20021
1 A26 test port 2 coupler to Port 2 CPLR ARM
E8363C, E8364C E8364-20044
W69
E8362C E8362-20022
1 A IN to A27 channel A mixer
E8363C, E8364C E8364-20045
W70
E8362C E8362-20029
1 R1 IN to A28 channel R1 mixer
E8363C, E8364C E8364-20075
W71
E8362C E8362-20030
1 R2 IN to A29 channel R2 mixer
E8363C, E8364C E8364-20076
W72
E8362C E8362-20023
1 B IN to A30 channel B mixer
E8363C, E8364C E8364-20046
W95
E8362C E8362-20032 1 A46 reference switch to channel R1 attenuator
E8363C, E8364C E8364-20119 1 A46 reference switch to A23 detector
W96 All E8364-20127 1 A45 reference switch to A46 reference switch
W97
E8362C E8362-20033
1 A46 reference switch to REF SOURCE OUT
E8363C, E8364C E8364-20121
W98
E8362C E8362-20034
1 A45 reference switch to REF R1 IN
E8363C, E8364C E8364-20123
W99
E8362C E8362-20043
1 A45 reference switch to A28 R1 mixer
E8363C, E8364C E8364-20152
