Theory of Operation
Interfaces
Analog Signal Output
The analog signal output can be distributed to a recording device. For
details refer to the description of the module’s main board.
GPIB Interface
The GPIB connector is used to connect the module with a computer. The
address and control switches next to the GPIB connector determine the
GPIB address of your module. The switches are preset to a default address
and recognized by the operating software from Agilent Technologies.
CAN Interface
The CAN is an intermodule communication interface. It is a 2-wire serial
bus system supporting high speed data communication and real-time
requirement.
Remote Interface
The APG remote connector may be used in combination with other
analytical instruments from Agilent Technologies if you want to use
features such as common shut down, prepare, and so on.
Remote control allows easy connection between single instruments or
systems to ensure coordinated analysis with simple coupling
requirements.
The subminiature D connector is used. The module provides one remote
connector which is inputs/outputs (wired-or technique).
Table 50 Default Addresses
Autosampler 28 Autosampler 28
Pump 22 RID 29
FLD 23
VWD 24 Autosampler (HP 1050) 18
Agilent 8453A 25 Pump (HP 1050) 16
DAD
/ MWD 26 VWD (HP 1050) 10
Column Compartment 27 DAD (HP 1050) 17
