Theory of Operation
Interfaces
Interfaces
The Agilent 1100 Series modules provide the following interfaces:
• CAN connectors as interface to other Agilent 1100 Series modules,
• GPIB connector as interface to the Agilent ChemStation,
• RS-232C as interface to a computer,
• REMOTE connector as interface to other Agilent products,
• Analog Output connector(s) for signal output, and
• Interface slot for specific interfacing (external contacts, BCD, LAN and
so on).
For identification and location of the connectors Figure 6 on page 27.
WARNING Never use cables other than the ones supplied by Agilent Technologies
to ensure proper functionality and compliance with safety or EMC
regulations, see “External Tray G1313-60004” on page 184.
Table 49 Agilent 1100 Series Interfaces
Interface Type Pumps Autosampler
DA Detector
MW Detector
FL Detector
VW Detector
RI Detector
Thermostatted
Column
Compartment
Vacuum
Degasser
CAN Yes Ye s Yes Yes Yes No
GPIB Yes Yes Yes Yes Yes No
RS-232C Yes Ye s Yes Yes Yes No
Remot e Ye s Ye s Yes Yes Yes Yes
Analog Yes No 2 × 1 × No
Yes
*
Interface board Yes Yes Yes Yes No No
*
The vacuum degasser will have a special connector for specific use. For details see description of main board.
