Agilent Technologies ICP-MS Series

2.4.4 Check torch box
(4) Check if shield/torch is correctly assembled.
Set the projection on
torch in the hole of the
shield plate .
Good
Set the projection on
torch in the notch of the
holder.
Good
Good contact between
shield plate and shield
contact.
Good
