Measurements 14
Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 233
This measurement is available for analog channels.
Negative Pulse Count
The Negative Pulse Count measurement is a pulse count for the selected
waveform source.
This measurement is available for analog channels.
Rising Edge Count
The Rising Edge Count measurement is an edge count for the selected
waveform source.
This measurement is available for analog channels.
Falling Edges Count
The Falling Edges Count measurement is an edge count for the selected
waveform source.
This measurement is available for analog channels.
Mixed Measurements
• "Area" on page 233
Area
Area measures the area between the waveform and the ground level. Area
below the ground level is subtracted from area above the ground level.
