Verification and Calibration Appendix B
Series N5700 User’s Guide 107
Test Record Form – Agilent N5747A and N5767A
Agilent N5747A and N5767A Report No _______________ Date __________________
Description Model Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Measurement Readback
High Voltage Vout
Measurement Readback
Both
Both
Both
Both
0 mV
Vout − 60 mV
59.94 V
Vout − 120 mV
__________
__________
__________
__________
+ 150 mV
Vout + 60 mV
60.06 V
Vout + 120 mV
CV Load Effect Both − 8 mV __________ + 8 mV
CV Source Effect Both − 8 mV __________ + 8 mV
CV Ripple and Noise
peak-to-peak
rms
Both
Both
N/A
N/A
__________
__________
60 mV
8 mV
Transient Response
Voltage @ 1ms
Both
− 300 mV
__________
+ 300 mV
Current Programming & Readback
Minimum Current Iout
Measurement Readback
High Current Iout
Measurement Readback
N5747A
N5767A
N5747A
N5767A
N5747A
N5767A
N5747A
N5767A
0 mA
0 mA
Iout − 37.5 mA
Iout − 75 mA
12.475 A
24.95 A
Iout − 50 mA
Iout − 100 mA
__________
__________
__________
__________
__________
__________
__________
__________
+ 63 mA
+126 mA
Iout + 37.5 mA
Iout + 75 mA
12.525 A
25.05 A
Iout + 50 mA
Iout + 100 mA
CC Load Effect
N5747A
N5767A
− 7.5 mA
− 10 mA
__________
__________
+ 7.5 mA
+ 10 mA
CC Source Effect
N5747A
N5767A
− 3.25 mA
− 4.5 mA
__________
__________
+ 3.25 mA
+ 4.5 mA
Test Description N5747A Setting N5767A Setting
Voltage Programming & Readback, Min Voltage ≤120 mV, 50 mA ≤120 mV, 100 mA
Voltage Programming & Readback, High Voltage 60 V, 50 mA 60 V, 100 mA
CV Load Effect, Source Effect, Ripple and Noise 60 V, 12.5 A 60 V, 25 A
Transient Response
60 V, from 1.25 A to 11.25 A
60 V, from 2.5 A to 22.5 A
Current Programming & Readback, Min Current 50 mA, 60 V 100 mA, 60 V
Current Programming & Readback, High Current 12.5 A, 60 V 25 A, 60 V
CC Load Effect, Source Effect 12.5 A, 60 V 25 A, 60 V
Load Requirements N5747A N5767A
Current shunt 0.1Ω 15 A 0.01Ω 100 A
Agilent N3300 Electronic load modules 2 – N3305A 3 – N3305A
Fixed Resistor for CV Ripple and Noise 4.8Ω 1kW 2.4Ω 2kW
