Agilent Technologies N5700 Series User Manual

Specifications Appendix A
Series N5700 User’s Guide 91
Outline Diagram
NOTES:
Holes marked “A” are for chassis slide mounting.
Use only screws designated #10-32x0.38” maximum.
482.8+/-1.0mm
43.6mm
VOLTAGE DC VOLTS DC AMPS CURRENT
PROT FINE LIMIT UVL OCP REM OUT ON
OVP
POWER
I
O
A
AA
A
N5749A
100V/7.5A 750W
System DC Power Supply
AAA
57.8+/-0.5
92.0+/-0.5 92.0+/-0.5
21.0
433+/-1.0mm
507.0+/-1.0mm
3
9
.
5
+
0
.
5
m
m
22.0mm
3.0mm
30.0mm
Bus-Bar Detail
6V to 60V Models
8.5mm
Strain-Relief Detail
1500W Models
35m
m
AC INPUT
ON
OFF
422.8+/-1.0mm
+V -V
NOT ACTIVE
J2
SW1
GPIB
ANALOG P ROG RAMM ING
+S+LSNC-LC-S
1 2 3 4 5 6 7 8 9
10/100 Ethernet
LINK
TX
J1
